Racer Globe Valves
What are Racer Globe Valves?
Racer Globe Valves are engineered flow control devices designed for precision throttling in pipelines. These valves feature a spherical body with an internal baffle and a movable plug or disc that regulates fluid flow. Known for their accuracy in modulating flow rates, Racer Globe Valves are used extensively in oil & gas, petrochemical, power, and HVAC systems.
Asiad Steel Industries is a trusted supplier of Racer Globe Valves, delivering performance-focused solutions tailored for demanding operational needs.
Key Features
- Precision Flow Control – Ideal for regulating flow with minimal leakage.
- Robust Construction – Built from high-grade steel and alloys for superior strength.
- Rising Stem Design – Enables easy visual indication of valve position.
- Leak-Tight Shutoff – Designed to withstand high-pressure environments.
- Global Standards Compliant – Manufactured as per ASME, API, BS, and DIN standards.
Specifications
Mechanical Properties
Chemical Composition
Equivalent Grades
Weight Chart
Specifications
| Parameter | Details |
|---|---|
| Sizes | ½” to 12″ (DN15 – DN300) |
| Pressure Ratings | Class 150 – 2500 / PN10 – PN100 |
| Design Standards | BS 1873 / API 623 / ASME B16.34 |
| Body Materials | CS, SS 304/316, Duplex, Alloy 20, etc. |
| Connection Types | Flanged, Screwed, Socket Weld |
| Property | Value |
|---|---|
| Tensile Strength | 480 – 750 MPa |
| Yield Strength | 250 – 500 MPa |
| Hardness | 125 – 250 HB |
| Elongation | 20% – 35% |
| Working Temp | -29°C to +550°C |
| Element | Composition (%) |
|---|---|
| Carbon (C) | 0.08 – 0.20 |
| Manganese | 0.50 – 1.50 |
| Chromium | 16.0 – 20.0 (SS) |
| Nickel | 8.0 – 11.0 (SS) |
| Molybdenum | 2.0 – 3.0 (316) |
| Phosphorus | ≤ 0.035 |
| Sulfur | ≤ 0.030 |
| Iron (Fe) | Balance |
| Standard | Equivalent Grade |
|---|---|
| ASTM | A105, A182 F304/316, F11 |
| DIN | 1.4301, 1.4401 |
| BS | 316S31, 304S11 |
| Valve Size | Class | Weight (kg) |
|---|---|---|
| 1″ | 150 | 5.5 |
| 2″ | 300 | 12.2 |
| 3″ | 600 | 25.6 |
| 4″ | 900 | 42.8 |
Applications of Racer Globe Valves
Construction &
Infrastructure
Automotive & Heavy
Equipment
Manufacturing &
Fabrication
Medical & Laboratory
Equipment
Electrical &
Electronics Assembly
Oil, Gas & Petrochemical
Installations
Do you have questions?
Can Racer Globe Valves handle high-pressure steam?
Yes, they are suitable for steam service up to Class 2500 ratings.
How does a globe valve differ from a gate valve?
A globe valve throttles flow, while a gate valve is typically for on/off control.
Are custom sizes available?
Yes, we supply customized globe valves on request.
What maintenance is required?
Periodic lubrication and seal inspection are recommended for optimal performance.
